2023 Trek Checkpoint SL 5 - Satin Mercury/Satin Carbon Smoke
Shop the 2023 Trek Checkpoint SL 5 at Biket — South Africa’s official Trek Bikes online store. Lightweight carbon gravel bike with IsoSpeed comfort, versatile geometry, internal storage and tyre clearance for up to 45–50 mm. Built for adventure, endurance rides or daily mixed-terrain cycling.
OVERVIEW
Checkpoint SL 5 is a carbon gravel bike made for epic all-road adventures. It's built with lightweight OCLV Carbon, terrain-smoothing damped IsoSpeed, nimble-yet-stable progressive geometry, internal storage and loads of mounts. All of that adds up to a rad gravel bike capable of crushing the longest, roughest rides and the most ambitious bikepacking trips.
It's right for you if...
Chamois or cut-off shorts, bikepacking trip or brutal day of gravel racing – you're going to ride far, go fast and have a great time. You want a bike that's both fast and comfortable, and you want endless carrying options for gravel races and everyday adventures.
The tech you get
A 500 Series OCLV Carbon frame with damped Rear IsoSpeed and carbon armour, a progressive geometry that's stable at speed and efficient when you're grinding up a climb, internal storage, hidden cables that won't interfere with bags, integrated frame bag mounts and rack and mudguard mounts. Plus, a carbon fork, a 2x11 Shimano GRX drivetrain with lower gears for grinding up hills or through rough gravel, and wide 700x40c gravel tyres for added stability and traction. You can even run a dropper post to get low on long descents.
The final word
Light, fast, comfortable. The Checkpoint SL 5 gives you the unmatched ride quality of an OCLV Carbon frame with IsoSpeed and gravel-specific geometry, plus internal storage and a drivetrain built for rough terrain.
Why you'll love it
- The damped, controlled rebound of the IsoSpeed decoupler soaks up fatiguing bumps without bouncing you around
- All-new progressive geometry is quick and nimble yet keeps you stable and in control on fast, choppy descents
- A sleek internal storage compartment gives you a versatile spot to stow tools and gear
- Massive tyre clearance means you can use tyres up to 45 c for extra traction and stability in any conditions
- Integrated frame bag mounts and rack and mudguard mounts make it easy to carry gear and water
Specifications
*spec applies to all sizes unless otherwise noted
| Frame | 500 Series OCLV Carbon, IsoSpeed, internal cable routing, downtube storage door, 3S chain keeper, T47 BB, rack and mudguard mounts, integrated frame bag mounts, flat-mount disc, dropper post compatible, 142x12 mm thru axle |
|---|
| Hub front | Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle |
|---|---|
| Skewer front | Bontrager Switch thru axle, removable lever |
| Hub rear | Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle |
| Skewer rear | Bontrager Switch thru-axle, removable lever |
| Rim | Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve |
| Spokes | 14 g stainless steel |
| Tyre | Bontrager GR1 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 120 tpi, 700x40 c |
| *Tyre part | Size: 49, 52, 54, 56, 58, 61 Bontrager TLR sealant, 180 ml/6 oz |
| Size: 49, 52, 54, 56, 58, 61 Bontrager XXX TLR valve, 50 mm |
|
| Rim strip | Bontrager Aeolus XXX rim strip |
| Shifter | Shimano GRX RX600, 11-speed |
|---|---|
| Front derailleur | Shimano GRX RX810, braze-on |
| Rear derailleur | Shimano GRX RX810, long cage, 34T max cog |
| *Crank | Size: 49 Shimano GRX RX600, 46/30, 165 mm length |
| Size: 52 Shimano GRX RX600, 46/30, 170 mm length |
|
| Size: 54, 56 Shimano GRX RX600, 46/30, 172.5 mm length |
|
| Size: 58, 61 Shimano GRX RX600, 46/30, 175 mm length |
|
| Bottom bracket | Praxis, T47 threaded, internal bearing |
| Cassette | Shimano 105 HG700-11, 11-34, 11-speed |
| Chain | Shimano 105 HG601, 11-speed |
| *Saddle | Size: 49, 52 Bontrager P3 Verse Comp, steel rails, 155 mm width |
|---|---|
| Size: 54, 56, 58, 61 Bontrager P3 Verse Comp, steel rails, 145 mm width |
|
| Seatpost | Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length |
| *Handlebar | Size: 49 Bontrager Elite Gravel, 38 cm width |
| Size: 52 Bontrager Elite Gravel, 40 cm width |
|
| Size: 54, 56 Bontrager Elite Gravel, 42 cm width |
|
| Size: 58, 61 Bontrager Elite Gravel, 44 cm width |
|
| Handlebar tape | Bontrager Supertack Perf tape |
| *Stem | Size: 49 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length |
| Size: 52, 54 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
|
| Size: 56, 58 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length |
|
| Size: 61 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length |
|
| Brake rotor | Shimano SM-RT70, CenterLock, 160 mm |
| Weight | 56 - 21.38 lbs / 9.7 kg |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
